MONDRAKER FOXY R FRAME

• FRAME: SuperFoxy 29 Stealth Air full Carbon, Zero Suspension System, 160mm travel, Forward Geometry, Carbon Monoblock upper link, SuperBoost 12x157mm rear axle, tapered head tube, 73mm BSA bottom bracket, dedicated 1x drivetrain design, HHG internal cable routing, Enduro MAX sealed bearings, shock mudguard, ISCG 05, custom frame protectors. *Geometry kit included
• SIZES: S: 380mm / M: 420mm / L: 470mm / XL: 510mm.
• REAR SHOCK: Öhlins TTX 22M Coil 205X65mm. Settings: high-speed compression lever with climb mode, low-speed compression, rebound, air preload. Trunnion top mount, 22.2x10mm bottom bushings.
• REAR SHOCK ADJUSTMENT: C10 compression, R35 rebound. Spring rate: S size 343 lbs, M size 411 lbs, L size 457 lbs, XL size 502 lbs.
• HEADSET: Onoff Krypton FG 30mm, CNC, 31.8mm barbore.
• REMOTE FORK CONTROL: Onoff Titan tapered for 1-1/8" to 1-1/2" head tube, ACB sealed bearings, top 41.8x30.5x8x45°x45°, bottom 51.9x40x8x45°x45°.
• REAR DERAILLEUR HANGER: Mondraker M071.
• WEIGHT WITHOUT PEDALS: *Geometry kit included: 0° headset cups and chainstay adaptor for 450mm CS length.
