MONDRAKER KIDS BIKE F-PLAY 26

MONDRAKER KIDS BIKE F-PLAY 26

The Mondraker F-Play 26 2026 is a junior electric bike designed for young riders who want to make real progress off-road. With its Mahle X-30 motor, integrated battery, and Zero Suspension system, it delivers responsive and stable handling on technical trails. Thanks to the Shimano Deore 12-speed drivetrain and powerful hydraulic disc brakes, it ensures reliability and safety in all conditions.

This model features a Stealth Evo aluminum frame with an integrated battery, X-Fusion Slant RC fork with 140 mm of travel, and X-Fusion 02PRO R rear shock with 130 mm of travel. Equipped with Shimano Deore 12-speed transmission, Shimano MT520 4-piston brakes, and Maxxis Minion tubeless-ready tires, it provides optimal grip on all terrains.

MONDRAKER KIDS BIKE F-PLAY 26 MAIN FEATURES:

• Wheel Size: 26"
• Gears: 12-speed
• Motor: Mahle
• Battery (Wh): 250
• Suspension Travel (mm): 140

THE BIKE IS DELIVERED PRE-ASSEMBLED BY US*

TECHNICAL SPECIFICATIONS

Frame

• F-Play 26 Alloy 6061 Stealth Evo, hydroformed tubes
• System: Zero Suspension, 130 mm travel
• Battery: integrated non-removable
• Head tube: tapered
• Cable routing: internal HHG
• Bottom bracket: BSA

Motor & Electronics

• Motor: MAHLE X30 Drive Unit, 250 W, 45 Nm
• Display: iWoc ONE Head Unit
• Battery: Mahle IX 250 Wh
• Charger: MAHLE Charger, 4 A

Suspension

• Fork: X-Fusion Slant RC 26, 140 mm coil
• Fork details: tapered steerer, 15×100 mm axle, 34 mm stanchions, 41 mm offset
• Fork adjustments: lockout, rebound, air preload
• Shock: X-Fusion 02PRO R, 165×45 mm
• Shock adjustments: low-speed rebound, air preload
• Shock mount: upper Trunnion, lower bushings 50×8 mm

Drivetrain

• Rear derailleur: Shimano Deore M6100, SGS, Shadow+, 12-speed
• Shifter: Shimano Deore M6100, RapidFire Plus, 12-speed
• Cassette: Sunrace CSMZ600, 11–51T
• Chain: Shimano Deore M6100, 12-speed, Quick-link
• Chainring: 30T, steel
• Crankset: Prowheel DMJ-CR094S-TT, direct mount chainring, 155 mm

Brakes

• Front brake: Shimano MT520, 4-piston caliper, resin pads
• Rear brake: Shimano MT520, 4-piston caliper, resin pads
• Rotors: SM-RT-56 180 mm

Wheels & Tires

• Front tire: Maxxis Minion DHF 26×2.5 WT, tubeless ready, 3C MaxxTerra, EXO, 60 TPI, folding bead
• Rear tire: Maxxis Minion DHR II 26×2.4, tubeless ready, EXO, 60 TPI, folding bead
• Rims: MDK-XP1 26 TLR, 25 mm inner width, tubeless ready, 32 spokes
• Front hub: DA210FS02, 15×100 mm, 6-bolt IS
• Rear hub: Mahle-Ebikemotion X-30, HG freehub

Components

• Handlebar: MDK XC 1.0, alloy 6061, 25 mm rise, 680 mm width, 9° backsweep, 5° upsweep, 31.8 mm clamp
• Stem: Onoff S3 30 mm 0°, forged alloy 6061, 31.8 mm clamp
• Saddle: SDG Fly JR
• Seatpost: X-Fusion Manic LC internal, 31.6 mm diameter, 1x remote, 125 mm travel

Additional Data

• Weight: 17.0 kg
• Maximum rider weight: N/A

*PRO-M STORE OFFERS FREE BIKE PRE-ASSEMBLY SERVICE: SEATPOST, FORK, DERAILLEUR AND BRAKES ARE ALREADY INSTALLED
