MONDRAKER DUNE R BIKE

DUNE R: DON'T CALL ME "ENTRY LEVEL"
The DUNE R doesn't compromise on anything compared to its more expensive siblings. A FOX 38 Float 3P Performance Grip fork with 170 mm keeps the front end in check, while the Fox Float X Performance EVOL shock handles the situation at the rear. The rear transmission is entrusted to the SRAM GX Eagle derailleur while the cranks are the e*thirteen E*Spec Plus, the ONOFF Pija telescopic seatpost, SRAM DB8 brakes, and e*thirteen Grappler Core wheels with 30 mm aluminum rims.

KEY FEATURES OF THE MONDRAKER DUNE R BIKE:

• Mullet.
• Zero suspension system.
• Forward Geometry.
• Stealth Carbon.
• Bosch.

THE BIKE IS DELIVERED PRE-ASSEMBLED BY US*

TECHNICAL SPECIFICATIONS

• FRAME: Stealth Air full Carbon, e-Bike Optimized Zero Suspension System, Mullet, 165mm travel, Forward Geometry, internal & removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 15mm axles, exclusive plastic motor covers.
• SIZES: S: 380mm / M: 420mm / L: 450mm / XL: 490mm.
• SHOCK: Fox Float X Performance EVOL, 505x65mm. Settings: 2-position compression (Open/Firm), rebound, air preload. Trunnion top mount, 30x8mm bottom bushings.
• SHOCK ADJUSTMENT: Medium compression, medium rebound, air volume spacer 0.4
• FORK: FOX 38 Float 3P Performance Grip, 170mm, e-bike tuned, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload.
• HEADSET: Acros custom for 1-1/2" head tube, angular contact bearings 40x52x7, Internal cable routing.
• STEM: Onoff Krypton FG 30mm, CNC, 31.8mm barbore.
• HANDLEBAR: Onoff Krypton 1.0, rise: 25mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore.
• GRIPS: Onoff Desert, 1lock-on, 135mm.
• SEATPOST: Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 405x95-125mm, M size: 458x120-150mm, L size: 498x140-170mm, XL size: 558x170-200mm.
• SEAT: Fizik Terra Aidon Slim X5.
• FRONT BRAKE: Sram DB8, oversized 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads.
• REAR BRAKE: Sram DB8, oversized 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads.
• BRAKE LEVERS: Sram DB8, tool reach adjust, lever pivot bushings.
• RIMS: e*thirteen Grappler Core, Hookless 6069 Welded Aluminum 30mm internal width, tubeless ready, 28F spokes 29 front, 27''5 rear.
• SPOKES: e*thirteen custom J-bend, triple-butted steel, alloy nipples, nipple washers.
• FRONT HUB: e*thirteen Boost 15x110mm, triple-sealed, fully machined aluminum, IS 6 bolts.
• REAR HUB: e*thirteen Boost 12x148mm, triple-sealed, fully machined aluminum w/6-degree engagement, IS 6 bolts.
• FRONT TIRE: Maxxis Assegai 29x2.5WT, tubeless ready, 3C MAXX GRIP compound, DH casing, 60x2TPI, folding bead.
• REAR TIRE: Maxxis Minion DHR II 27’5x2.4 WT, tubeless ready, 3C MaxxTerra compound, DD protection, 2x120TPI, folding bead.
• CRANKSET: E.13 E*Spec Plus,, S size: 165mm M size: 165mm L size: 170mm XL size: 170mm.
• CHAINRING: Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD.
• CHAIN: Sram NX Eagle, 12s, Powerlock.
• REAR DERAILLEUR: Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1.
• SHIFT LEVER: Sram Trigger NX Eagle, 12s, X-Actuation 1:1, single click.
• TAPE: Sram PG-1230, 11-50T, 12s.
• DROPOUT: Sram UDH.
• WEIGHT: 19.9KG.
• DISPLAY: Bosch Kiox 500 / Bosch Mini Remote / Bosch System Controller.
• MOTOR: Bosch Performance Line SX (25Km/h) GEN4 SMART SYSTEM Diagonal, Wide.
• BATTERY: Bosch Compact Powertube 400Wh.

*PRO-M STORE OFFERS FREE ASSEMBLY SERVICE FOR THE BIKE: SEATPOST, FORK, DERAILLEUR, AND BRAKES ARE ALREADY INSTALLED
