Chisel Comp

The Chisel is the lightest alloy full-suspension bike in the world. It is 18.4% lighter than similar models in its category and, thanks to the kinematics and geometry of its big sister, the Epic 8, the Chisel delivers outstanding performance on every ride.

Chisel Comp main features:

• SPEED METAL: Featuring D'Aluisio Smartweld, the Chisel boasts the lightest XC aluminum frame in its category, with highly manipulated tubing and varied thicknesses and profiles for efficiency, vibration absorption, comfort, and optimal control.
• CAPACITY: Equipped with 110mm Ride Dynamics-tuned suspension, the Chisel inherits its high-performance pedigree directly from the Epic 8, our World Cup racing machine. Advanced suspension kinematics DNA from the Epic 8, Ride Dynamics-tuned suspension, and progressive geometry refined on World Cup technical tracks can all be found in the Chisel, making it more than capable of handling diverse terrains with confidence and speed.
• EFFICIENCY: The Chisel is the most efficient bike in its category, thanks to the geometry and kinematics developed for the Epic 8. The advanced seat tube positions the rider optimally for pedaling. Optimized anti-squat reduces pedal-bob. Put it all together, and you'll understand how the Chisel translates every watt on the pedals into maximum forward motion.
• SMOOTHER IS FASTER: Flex Stay seatstays were designed to be category-leading in suspension performance while eliminating the additional weight and maintenance of joints used in traditional designs. Extensive field and lab testing have shown that the Chisel has achieved the impossible: the efficiency, control, and lightness of the Flex Stay design – common on carbon bikes – with an advanced alloy.
• HYDROFORMED ALLOY: The hydroformed one-piece seat tube includes the bearing seat and bottom bracket shell, unlike a traditional alloy bike where the two components are welded. This further shaves material and weight off the Chisel.

Cockpit
Saddle
Body Geometry Power Sport, steel rails
Handlebar
Specialized Alloy, 20mm rise, 31.8mm, 760mm width
Grips
Specialized Trail Grips
Stem
Specialized, 3D-forged alloy, 4-bolt, 7-degree rise
Seatpost
TranzX Dropper, 30.9mm, XS: 100mm, SM-M: 125mm, L-XL: 150mm

Drivetrain
Bottom Bracket
SRAM DUB, BSA 73mm, Threaded
Crankset
SRAM X1000 Eagle, DUB, 165/170/175mm
Rear Derailleur
SRAM GX Eagle, 12-speed
Shifters
SRAM GX, trigger, 12-speed
Cassette
SRAM PG-1230 Eagle, 11-50t
Chain
SRAM SX Eagle, 12-speed
Chainring
32T

Frame
Frame
Specialized D'Aluisio Smartweld M5 Alloy, Hydroformed tubes, Progressive XC Geometry, 110mm travel, internal cable routing, BSA bottom bracket, 12x148mm spacing, compatible with 30.9mm dropper post
Seat Collar
Specialized Alloy, 34.9mm

Suspension
Fork
RockShox SID, Rush damper, 44mm offset, 15x110mm thru-axle, 120mm travel, Maxle Stealth
Rear Shock
RockShox Deluxe Select+, Ride Dynamics Tuned, Two Position, Rebound Adjust, 190x40mm

Brakes
Front Brake
SRAM Level T hydraulic disc, 2-Piston Caliper, 180mm rotor
Rear Brake
SRAM Level T hydraulic disc, 2-Piston Caliper, 160mm rotor

Wheels
Rear Hub
Specialized alloy, disc, sealed cartridge bearings, 6-bolt, 12x148mm thru-axle, 28h
Rear Tire
Specialized Fast Trak, Control Casing, T5 Compound, 29x2.35
Front Tire
Specialized Ground Control, Control Casing, T5 Compound, 29x2.35
Rims
Specialized Alloy, Tubeless ready, 27mm inner width, disc, 28h
Tubes
Standard 40mm Presta Valve, 29x1.75–2.4
Front Hub
Specialized alloy front hub, disc, sealed cartridge bearings, 6-bolt, 15x110mm thru-axle, 28h
Spokes
Stainless steel, 14g

Weight
Weight
12.80 kg (28 lb, 3.5 oz)
Measured Size
MD
